2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
Series 2800 Precision Globe Control Valves are available with a
variety of actuators and accessories. These actuators and accessories
have separate instructions. For complete control valve installation,
operation, and maintenance instructions see also the instructions
for the actuator and accessories in use.
VALVE IDENTIFICATION
To use these instructions it is necessary to identify the configuration
of the valve. Factory assembled control valves have a nameplate
mounted on the actuator. The valve’s part number (P/N) is present
on the plate. The part number represents the configuration of the
control valve. To identify the valve’s type, size, actuator, accessories,
and other characteristics decode the part number using configura-
tion table. If the information is incomplete, incorrect, or not pres-
ent contact the factory with the valve serial number listed on the
plate. (See Information Present on Control Valves section for location
of part number, serial number, and other important information on
valve.)
ACTUATORS AND ACCESSORIES
Valve
Type
Size
Body Ma
terial
End
Connection Trim Style Trim Material Trim Cv
20
2-Way
Single Seat
28
2-Way
Lo-Flow
30
3-Way
Mixing
32
3-Way
Diverting
050
1/2 inch
075
3/4 inch
100
1 inch
125
1-1/4
inch
150
1-1/2
inch
200
2 inch
B
Bronze
F
CF8M
S
Screwed
B
SCH 40
Buttweld End
F
Full Port
1
1st Port
Reduction
2
2nd Port
Reduction
3
3rd Port
Reduction
4
4th Port
Reduction
NOTE:
Port reductions
only available on
Type 20/28/30.
Check factory for
availability.
Model
Packing Type
T
Teflon
G
Graphite
V
Vacuum Service
L
EPDM
Stainless Steel,
Type 20 Bodies
come standard w/
PEEK bearings. Used
for Temp. up to
500°F.
VALVE BODY
28N
E
Equal %
L
Linear
M
Mod Lin
Types 30/32,
Linear Only
Types 28
Mod Lin Only
S
316SS *
B
Bronze
6
Alloy 6
H
17-4 PH
T
Teflon
P
PEEK
NOTE:
* Type 28, 316SS
trim uses
harder
Nitronic
60 seat.
TEMPERATURE LIMITS
Valve
Type
Body
Material
& Code Trim Material & Code Packing Type & Code T MAX T MIN
20 2-Way
Single Seat
Bronze B 316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK P EPDM L 350ºF -20ºF
Bronze B 316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK P Teflon T, Vacuum Service V 400ºF 32ºF
Bronze B 316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK P Graphite G 400ºF -20ºF
CF8M F 316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK P EPDM L 350ºF -20ºF
CF8M F 316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK P Teflon T, Vacuum Service V 450ºF 32ºF
CF8M F Teflon T, PEEK P Graphite G 450ºF -20ºF
CF8M F 316 S, 17-4 PH H, Alloy 6 6 Graphite G 500ºF -20ºF
28 2-Way
Low Flow
Bronze B 316 S, Teflon T, PEEK P EPDM L 350ºF -20ºF
Bronze B 316 S, Teflon T, PEEK P Teflon T, Vacuum Service V 400ºF 32ºF
Bronze B 316 S, Teflon T, PEEK P Graphite G 400ºF -20ºF
CF8M F 316 S, Teflon T, PEEK P EPDM L 350ºF -20ºF
CF8M F 316 S, Teflon T, PEEK P Teflon T, Vacuum Service V 450ºF 32ºF
CF8M F Teflon T, PEEK P Graphite G 450ºF -20ºF
CF8M F 316 S Graphite G 500ºF -20ºF
30 3-Way
Mixing
Bronze B 316 S EPDM L 350ºF -20ºF
Bronze B 316 S Teflon T, Vacuum Service V 400ºF 32ºF
Bronze B 316 S Graphite G 400ºF -20ºF
CF8M F 316 S EPDM L 350ºF -20ºF
CF8M F 316 S Teflon T, Vacuum Service V 450ºF 32ºF
CF8M F 316 S Graphite G 500ºF -20ºF
32 3-Way
Diverting
Bronze B Bronze B Teflon T, Vacuum Service V 300ºF 32ºF
Bronze B Bronze B Graphite G, EPDM L 300ºF -20ºF
CF8M F 316 S EPDM L 350ºF -20ºF
CF8M F 316 S Teflon T, Vacuum Service V 450ºF 32ºF
CF8M F 316 S Graphite G 500ºF -20ºF
