WARRIOR 57342 - Page 21

Page 21;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
J,($ U*#4("/$"&8 o$V
71 Cap 1
72 Washer Ø4x12x1 4
73 Lower Guard 1
74 Blade Nut 1
75 Outer Flange 1
77 Inner Flange 1
78 Blade Cover Plate 1
79 Screw M4x12, Spring Washer, Washer 3
80 Cap 1
81 Bearing 6003 (Z2) 1
82 Woodruff Key 4x5x13 1
83 Output Axis 1
84 Big Gear 1
85 External Retaining Ring Ø17 1
86 Bearing 619/8 (Z2) 1
87 Angle Seat 1
88 Hex Bolt M6x10 4
89 Motor Fixed Plate 1
90 Nut 1
91 Gear Box 1
92 Screw M5x30, Spring Washer, Washer 4
93 Shroud 1
94 Screw ST4.8x60 (C) 2
95 Stator 1
96 Bearing 6201 (Z3) 1
97 Rotor
98 Bearing 6000 (Z3) 1
99 Motor Housing 1
100 Motor Housing Cover 1
101 Power Cord Connector 1
102 Screw ST4.2x16 6
103 Power Cord Plate 2
104 Brush Holder 2
105 Brush Holder Cap 2
106 Carbon Brush 2
107 Wool Washer 1
108 Washer Ø5x10x1 2
109 Screw M5x12 4
110 Screw Rod 1
111 Bevel Gear 2
112 Screw M4x20, Washer 2
J,($ U*#4("/$"&8 o$V
113 Screw Rod Sleeve 1
114 Washer Ø8x17x1.5 1
115 Leaf Spring 1
116 Miter Gauge Holder 1
117 Push Stick Holder 2
118 Power Cord 1
119 Power Cord Sleeve 1
120 Housing 1
121 Screw ST4.2x20 3
122 Power Switch Box Bracket 1
123 Power Switch Box 1
124 Power Switch 1
125 Screw M5x14 3
126 Rack 1
127 Angle Scale 1
128 Angle Indicator 1
129 Angle Knob 1
130 Washer Ø6x22x2 1
131 Limit Plate 2
132 Saw Blade Gasket 1
133 Saw Blade Fixed Plate 1
134 Hex Bolt M 6x25 1
135 Knob 1
136 Screw M5x16, Spring Washer, Washer 1
137 Height Handle 1
138 Height Knob 1
139 Lifting Rocker 1
140 Hex Bolt M5x12, Spring Washer, Washer 5
141 Bracket 1
142 Sleeve 1
143 Bracket 1
144 Angle Seat 1 1
145 Backer Cover 1 1
146 Aluminium Profile 1
147 Backer Cover 2 1
148 Bolt M6×25 2
149 Knob 1
150 Miter Gauge 1
151 Miter Gauge Guide 1
152 Push Stick 1
153 Wrench 2
