WARRIOR 57342 - Parts and Warranty; Parts List

Page 20 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
J,($#%T"#$%,89%U",3(,5
J,($#%T"#$
J,($ U*#4("/$"&8 o$V
1 Cap 1
2 Nut M6 2
3 Spring 1
4 Plate 1
5 Cap 1
6 Fence Draw Bar 1
7 Fence 1
8 Hex Bolt M6x12, Spring Washer, Washer 2
9 Knob 5
10 Screw M4x10, Spring Washer, Washer 4
11 Rip Fence Indicator 1
12 Fence Seat 1
13 Fence Lock 1
14 Set Screw 1
15 Screw M5x10 2
16 Locking Plate 2
17 Cap 1
18 Sliding Fence 1
19 Bolt M6×50 2
20 Cap 1
21 Locking Plate 1
22 Blade Guard Bracket 1
23 Screw M5x10, Spring Washer, Washer 2
24 Bolt M6×16 4
25 Cap 1
26 Scale Base 1
27 Rip Fence Scale 1
28 Fixed Plate 4
29 Washer Ø6x12x0.8 7
30 Spring Washer 4
31 Cap 1
32 Nut M6 4
33 Hex Bolt M6x25, Spring Washer, Washer 4
34 Rotating Base 1
35 Rotating Friction Plate 1
J,($ U*#4("/$"&8 o$V
36 Bracket 2
37 Gasket 2
38 Screw ST4.2x10 6
39 Angle Guard Plate 1
40 Angle Guard 1
41 Angle Guard Spring 1
42 Hex Bolt M6x16, Spring Washer, Washer 6
43 Washer Ø6x18x1.5 6
44 Handle 2
45 Main Table 1
46 Table Insert 1
47 Screw M4x 5 6
48 Blade Guard Spring Clip 2
49 Screw 4
50 Blade Guard (Left) 1
51 Nut M5 6
52 Washer Ø5x14x1 1
53 Blade Guard Lock 1
54 Blade Guard Bracket 1
55 Riving Knife 1
56 Spring 1
57 Bracket Fixed Pin 1
58 Locking Screw 1
59 Riving Knife Pin 5 X 32 1
60 Blade Guard (Right) 1
61 Lifting Friction Pad 1
62 Riving Knife Bracket 1
63 Hex Bolt M6x20 2
64 Pin 8x16 2
65 Riving Knife Plate 1
66 Spring 1
67 Pin 5x32 1
68 Cylindrical Pin 8x16 1
69 Riving Knife Handle 1
70 Spring 1
