Wascomat W677 - Door Lock Repairs and Replacement

80
Door and door lock
4
6111
Repairs
Repair work on the machine should only be
done by specially trained personnel.
Emergency opening of door lock
1. Take down power from the machine by tur-
ning the main power switch to the 0 position.
2. Remove the front cover or top cover. When
replacing the door lock, it is recommended to
remove the front cover.
3. Press down the emergency opening button.
4
