Installation
WARNING
Installation personnel must be suitably qualified and ensure compliance with all
codes and standards.
IMPORTANT
Failure to comply (even partially) with the instructions given in this manual will
invalidate the product warranty and relieves the manufacturer of any responsibility.
Install machine on sound waterproof self-draining floor and use adjustable feet to
level machine.
Recommended bench depth = 600 mm, height = 900 mm – see Bench Details
diagram.
In corner installations the front of the machine must face to the left of the corner.
Allow room for detergent to one side of machine or in adjacent cupboard. 20litre
container requires about 450H x 250W x 350D, but smaller containers are available
from many suppliers.
Water Supply
Temperature 65°C ± 5°C
Pressure 100-200 KPa (15-30 Psi) with rinse pump
200-400 KPa (30-60 Psi) without rinse pump
Flow rate minimum 20 litres per minute
Consumption 3 litres per cycle approximately
Connection 20 mm (3/4" BSP Male)
IMPORTANT
Installation shall comply with requirements of AS 3500.1.
Flush supply line before connection.
Do not use small diameter plastic supply lines.
Line strainer is recommended.
Booster pump is available option for low pressure.
Pressure limiter is required over 400 KPa
Waste
40 mm – refer point B on the Installation Diagram on the next page. Directly
behind the machine, through knock outs in side panels or through hole in base.
Power
Electrical supply required is 15A 240V 50Hz via switched outlet adjacent to
machine, which is supplied with cord set including 15A plug.
Troubleshooting
If the machine doesn’t fill after switching on the power, check and ensure that the
hot water supply tap is open, water supply pressure is not below specification and
Dual Check Valve is not faulty and correctly installed (arrows on the dual check
valve’s body specify water flow direction).
Service Manual M1-3 (W) 5 Revision 1B
