Watchguard Firebox T15 User Manual

6 7
• Inspects outgoing FTP, HTTP, and HTTPS trac
• Uses licensed security services to protect the trusted and optional networks
Next Steps
Congratulations! You have nished basic setup of your Firebox. You can use the Web UI to
view and edit your conguration and to manage and monitor your Firebox. Or, you can
download and install WatchGuard System Manager (WSM) and use Policy Manager and the
WSM suite of management and monitoring tools. Here are some recommendations to help
you get started:
Verify your Internet connectivity
• With your Firebox installed in your network, make sure that your users can successfully
browse the Internet.
Get the latest software
To upgrade the Firebox OS:
1. Log in to Fireware Web UI.
2. Select System > Upgrade OS.
To get the latest version of WSM, WatchGuard Dimension, VPN clients, and other
software for your Firebox:
1. Go to www.watchguard.com/support and click Download Software.
2. Find the software downloads page for your Firebox model and select the
software you want to install.
Explore the features and functions of your Firebox
Browse the Web UI or the tools in WatchGuard System Manager and click Help on any
page or dialog box to learn more about the management, monitoring, and security
features of your Firebox.
About the Device Status Lights
Fail Over – Lights when there is a WAN failover from the primary external interface to the
backup interface.
WAP - (Wireless models only) Lights when the device is activated as a wireless access point
or as a wireless client.
Network interface status indicators – The three network interfaces are labeled 2, 1/LAN,
0/WAN. There are two status indicators for each interface.
Indicator Indicator color Interface Status
1000 Yellow Link speed: 1000 Mbps
Blinks* Data sent and received
10/100 Green Link speed: 10 Mbps or
100 Mbps
Blinks* Data sent and received
* Blink speed increases as the data ow increases
Status – Shows when there is a management connection to the device. The Status
indicator is lit for 30 seconds after you connect to the device with the Fireware Web UI or
the command line interface. It is also lit when the device is polled by WatchGuard System
Manager.
Mode – Shows the status of the external network connection. If the device can connect
to the external network and send trac, the indicator is green. The indicator ashes if the
device cannot connect to the external network and send trac.
Attn – Lights when you start the device with the Reset button pressed.
Power ( ) – The power indicator is lit when the device is on.
English

Watchguard Firebox T15 Specifications

General

Firewall throughput	400 Mbit/s
Branch Office VPN	5
IPS/IDS throughput	160 Mbit/s
Maximum firewall connections	100000
Maximum firewall connections per second	2400
DHCP client	Yes
Number of VLANs	10
Number of users	200 user(s)
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	3
Gigabit Ethernet (copper) ports quantity	4
Supported network protocols	IPv6
VPN support	IPSec, SSL, L2TP
Firewall security	DoS, HTTP, HTTPS, SMTP, FTP, DNS, TCP, POP3, SIP, H.323
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, 802.1x RADIUS, DES, MD5, SHA-1, SSL/TLS
Power supply	15 W
Input current	1.25 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Certification	WEEE, RoHS, ICSA, NRTL/C, CB
Heat dissipation	51 BTU/h
Mean time between failures (MTBF)	129955 h
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Dimensions (WxDxH)	190 x 152 x 32 mm
