Watchguard Firebox T15 User Manual

8 9
Reset the Device to Factory-Default Settings
If you ever need to, you can restore your Firebox to its factory-default settings. For
example, if you do not know the administrator account passphrase or you want to start
over with RapidDeploy QuickStart, you can reset your device. Make sure you back up your
conguration before you upgrade. The conguration can be restored if necessary.
For more information, see the Hardware Guide for your Firebox, available at:
https://www.watchguard.com/wgrd-help/documentation/hardware-guides
激活设备
1.访问 www.watchguard.com/activate
2.登录您的 WatchGuard 帐户，或者创建一个新帐户*。
*如果创建新帐户，请在完成帐户创建过程之后返回到 www.watchguard.com/activate。
3. 输入设备的序列号。
4. 在激活期间，选择设置方法：
• RapidDeploy QuickStart（RapidDeploy 快速部署） – 自动下载快速部署配置
文件并将其应用到您的设备，其中预配置了 WatchGuard 推荐的安全设置。
• Classic Activation（常规激活）–使用网络设置向导为您的设备创建一个基本
的配置文件。
5. 请根据您选择的方法使用本手册中对应的设置说明。
简体中文

Watchguard Firebox T15 Specifications

General

Firewall throughput	400 Mbit/s
Branch Office VPN	5
IPS/IDS throughput	160 Mbit/s
Maximum firewall connections	100000
Maximum firewall connections per second	2400
DHCP client	Yes
Number of VLANs	10
Number of users	200 user(s)
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	3
Gigabit Ethernet (copper) ports quantity	4
Supported network protocols	IPv6
VPN support	IPSec, SSL, L2TP
Firewall security	DoS, HTTP, HTTPS, SMTP, FTP, DNS, TCP, POP3, SIP, H.323
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, 802.1x RADIUS, DES, MD5, SHA-1, SSL/TLS
Power supply	15 W
Input current	1.25 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Certification	WEEE, RoHS, ICSA, NRTL/C, CB
Heat dissipation	51 BTU/h
Mean time between failures (MTBF)	129955 h
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Dimensions (WxDxH)	190 x 152 x 32 mm
