Operation During A Power Failure
In the event of a power failure, the valve will keep track of the time and day for 48 hours.
The programmed settings are stored in a non-volatile memory and will not be lost during a
power failure. If power fails while the unit is in regeneration, the valve will finish regenera-
tion from the point it is at once power is restored. If the valve misses a scheduled regen-
eration due to a power failure, it will queue a regeneration at the next regeneration time
once power is restored.
Main Display
When power is supplied to the control, the screen will display TIME OF DAY, GALLONS RE-
MAINING, and DEALER NAME and PHONE NUMBER.
The brine tank is equipped with a safety float which prevents your brine tank from overfill-
ing as a result of a malfunction such as a power failure.
Safety Float
New Sounds
You may notice new sounds as your water softener operates. The regeneration cycle lasts
up to 180 minutes. During this time, you may hear water running intermittently to the drain.
About The System
When the system capacity is near exhausted, a regeneration is necessary to restore the sys-
tem to full capacity. The table below explains the regeneration steps.
Regeneration Process
Step Name Description
#1 BackWash
Freshwa te r isintroducedtothebottomofthe tankflowin gupwardsexpandingthe ion
exchangere sintorinseoutanydirtorsmallparticl estothedrai n andtoun‐compa ct
thebed torestorefullserviceflowrates.
#2 Brine
Thebrinesolutionisintroducedslowlyfromthetopofth
eta
nkflowingdownthroug h
theionexchangere sinpushingthe hardne ssouttodrainandrestoringsystemcapacity.
#4 Rinse
Freshwa te r isintroducedfromthe topofthe tankflowingdownthroughtheion
exchangere sinrinsinganyexces sbrinesolutionouttothe drai n.
#5 Refill
Freshwa te r isaddedtoth
esal
ttanktopre pa re andinsurefullysaturatedbrineforthe
ne xtregen eration.
10
