Capacity
Model
Nominal 32,000 Grain Units (-32)
# of People 1 2 3 4 5 6 7 8 9
Salt Setting 15 lbs. / Regeneration
Hardness Range Number Of Tabs To Pull
3 - 10 1 1 1 2 2 2 2 3 3
11 - 20 1 2 2 3 3 4 4 4 4
21 - 30 1 2 3 4 6 6 6 12 12
31 - 40 2 3 4 6 6 12 12 12 -
41 - 50 2 3 6 6 12 12 12 12 -
51 - 60 2 4 6 12 12 12 12 - -
61 - 75 2 4 6 12 12 12 - - -
NOTE: The number found in the above sample chart is the number of program tabs that will need to be pulled (slide out)
on the program wheel. Simply align the Number of People with the Compensated Hardness to find the number of tabs to
slide. When you have determined the number of tabs to slide, consult the regeneration frequency chart below to find the
actual “tab number(s)” to slide out on the program wheel.
Figure 3
Regeneration Frequency Slide Out TAB NUMBER
(# of Tabs Out) 1 2 3 4 5 6 7 8 9 10 11 12
12
● ● ● ● ● ● ● ● ● ● ● ●
6
● ● ● ● ● ●
4
● ● ● ●
3
● ● ●
2
● ●
1
●
NOTE: Figure 1 shows the skipper wheel set for the example (every 2 days).
Figure 2
10
- How To Use The Capacity Charts -
EXAMPLE
HARDNESS = 20 gpg 20 gpg UNIT SELECTED 32,000 GRAIN
IRON = 3 ppm X 4 12 gpg NUMBER OF PERSONS 4
MANGANESE = 1 ppm X 4 4 gpg COMPENSATED HARDNESS 36 gpg
TOTAL COMPENSATED HARDNESS 36 gpg SALT SETTING 15 LB/ REG
