WaterSoft DS32P - Programming DS Units Control Valve

Capacity
Model
Nominal 48,000 Grain Units (- 48)
# of People 1 2 3 4 5 6 7 8 9
Salt Setting 24 lbs. / Regeneration
Hardness Range Number of Pins to Pull
3 - 20 1 1 2 2 2 3 3 3 4
21 - 30 1 2 2 3 3 4 4 6 6
31 - 40 1 2 3 3 4 6 6 6 12
41 - 50 1 2 3 4 6 6 12 12 12
51 - 60 2 3 4 6 6 12 12 12 12
61 - 70 2 3 4 6 12 12 12 12 12
71 - 80 2 3 6 6 12 12 12 12 -
81 - 90 2 4 6 12 12 12 12 - -
91 - 100 2 4 6 12 12 12 - - -
Model
Nominal 64,000 Grain Units (-64)
# of People 1 2 3 4 5 6 7 8 9
Salt Setting 30 lbs. / Regeneration
Hardness Range Number of Pins to Pull
3 - 20 1 1 1 2 2 2 2 3 3
21 - 30 1 1 2 2 3 3 3 4 6
31 - 40 1 2 2 3 3 4 4 6 6
41 - 50 1 2 3 3 4 6 6 12 12
51 - 60 1 2 3 4 6 6 6 12 12
61 - 70 1 2 3 4 6 6 12 12 12
71 - 80 2 3 4 6 6 12 12 12 12
81 - 90 2 3 4 6 12 12 12 12 -
91 - 100 2 3 4 6 12 12 12 - -
- Programming The Control Valve For “DS” Units -
Figure 1
12
