WaterSoft Provectr Plus AF10AC-3 - Bypass Assembly; D15 Bypass Valve; 1 NPT Elbow Set; 1 Female Straight Slip Set

17
1
4
2
3
7
5
6
REF DESCRIPTION PART NO.
1 D15 Bypass (included with all units) 20017X283
2 1” NPT Elbow Set (included with all units) 20017X284
3 1” Female Straight Slip Set (optional) 20017X288
4 1” NPT Straight Set (optional) 20017X289
5 3/4” NPT Straight Set (optional) 20017X307
6 1” X 3/4” Brass Sweat Connector Set (optional) 20017X304
7a Elbow, Vertical Adapter Blank (optional) 20017X295
7b Elbow, Vertical Adapter 1/4” NPT Tapped (optional) 20017X294
Bypass Assembly
