Watson-Marlow 730 Bp - Page 2

11.2 Wiring the US NEMA module 19
11.3 Earth screening of control cables on NEMAmodule 19
12 Start-up check list 20
13 Control wiring 21
13.1 Upper D-connector 21
13.2 PROFIBUS 21
14 Switching the pump on for the first time 30
14.1 Selecting the display language 30
14.2 First-time start-up defaults 32
15 Switching the pump on in subsequent power cycles 34
16 Mode menu 35
17 Manual 36
17.1 START 36
17.2 STOP 37
17.3 INCREASING AND DECREASING FLOW RATE 37
17.4 MAX FUNCTION (Manual mode only) 38
18 Flow calibration 39
18.1 Setting the flow calibration 39
19 PROFIBUS mode 42
19.1 MODE menu 42
19.2 Manual mode operation when PROFIBUS is enabled 42
19.3 PROFIBUS mode 44
19.4 Assigning the PROFIBUS station address at the pump 46
19.5 PROFIBUS communication errors 47
19.6 PROFIBUS GSD file 49
20 Main menu 52
20.1 Security settings 54
20.2 General settings 65
20.3 Help 76
21 Troubleshooting 77
21.1 Leak detection 78
21.2 Error codes 78
21.3 Technical support 79
2 m-730bpn-en-08.1
