26.3 Pumphead spares
Continuous tubing models 720R and 720RX
Number Spare Description
1 MRA3062A Rotor assembly (720R)
1 MRA0036A Rotor assembly (720RX)
2 MRA0104A Knob assembly (4.8mm wall tubing)
3 CN0090 Coupling half
4 MR0880C Tube clamp
5 MRA3061A Foot assembly
6 CN0229 M12 blanking plug
7 CN0088 Coupling spider
8 MRA0027A Pivot pin assembly
8 MRA0034A Pivot pin assembly (720RX)
9 FN0611 M8 x 16mm screw
m-730bpn-en-08.1 89
