Figure 2-1e: Benchmark Model 5000 & 6000 Clearances
WARNING!
Keep the unit area clear and free from all combustible materials and flammable vapors or
liquids.
FOR MASSACHUSETTS ONLY:
For Massachusetts installations, the unit must be installed by a plumber or gas-fitter licensed
within the Commonwealth of Massachusetts. In addition, the installation must comply with all
requirements specified in Section 1.4, above.
2.4.2 Setting the Unit
If anchoring the unit, refer to Figure 2-2a through 2-2e for anchor locations.
• All holes are flush with the bottom surface of the frame.
• All dimensions shown are in inches [millimeters]
