TnP Prime User Manual Wavecom
Loading the Ribbon
To begin, open the printer top cover by pulling the tabs located on each side towards the front of the printer,
and then lift the top cover to the maximum open angle. You will also need to remove the old ribbon (which will
be spooled under the top cover shown in step 1) before loading a new ribbon. To remove this ribbon, simply
hold the ribbon roll and move it to the right (away from the blue gear).
1. Open the top cover of your Printer
4. Push the ribbon into the right axle (black), then
align the notches on the left and insert the
ribbon onto the gear (blue)
2. Insert an empty core between the gear and the axle
- ensure the notches align as shown
3. Open the printer. and get the thermal transfer
ribbon ready. Ensure the ribbon unwinds from
underneath as shown in Step 5
