WAVECOM Decoder W74PC, W-PCI/e, W-CODE, W-CLOUD Manual V9.1.0 First start

59
File Input Parameter
Value
Input Name
The name of the custom input
Device
Select File in the list
File Path
The path to the specific WAV-file has to be specified
Channel
In the list box the channel(s) to be used are displayed: Mono, Left, Right, Left + Right
(PCM) and Left & Righe (IQ).
If you start by entering the filename, then the file is analyzed and the correct settings are
automatically selected
Play Continuous
Indicates if the files are played in repeat mode. Select On to switch on the repeat mode or
Off to switch off the repeat mode
The file can be selected from any available directory on the LAN. The specified WAV-file is copied to the
Data-Input directory (on the computer hosting the decoder) and stored under the name
<SerialNumberOfW[xx]Card>_<InputName>.wav.
Note: The WAV-file is reloaded each time the Apply button is pressed. The Apply button must also be
used to save the configuration of a new custom input. Pressing the OK button only closes the dialog. The
XML file CustomInputs.xml, located in the Config directory, is updated by pressing the Apply button.
Add a New Sound Card (Real or Virtual) Custom Input
Select the Configuration | Custom Inputs... menu entry to open the configuration dialog for the custom
inputs.
To use a sound card as the signal input source, the following parameters have to be set via the Custom
Inputs dialog:
Soundcard Input Parameter
Value
Input Name
The name of the custom input
Device
Select Soundcard in the list
Name
The names of all soundcards installed on the computer are displayed in a list box.
Select one soundcard
Channel
In the list box the channel(s) to be used are displayed: Mono, Left, Right, Left +
