Power Supply Voltage
V
MIN
V
NOM
V
MAX
VBATT 3.3 V (*) 3.6 V 4.5 V (**)
VDD 3.1 V 4.5 V
Table 1: Power supply voltage
(*): This value has to be guaranteed during the burst (with 2.0 A Peak in GSM or
GPRS mode).
(**): max operating Voltage Stationary Wave Ratio (VSWR) 2:1.
When the module is supplied with a battery, the total impedance
(battery+contacts+protections+PCB) should be < 150 mΩ to limit voltage drop-
out within emission burst.
As the radio power amplifier is directly connected to VBATT, the module is
sensitive to any Alternative Current on lines. When a DC/DC converter is used,
Wavecom recommends to set the converter frequency in such a way that the
resulting voltage does not exceed the values in following table and Figure 2.
Freq.
(kHz)
U
ripp
Max
(mVpp)
Freq.
(kHz)
U
ripp
Max
(mVpp)
Freq.
(kHz)
U
ripp
Max
(mVpp)
<100 50 800 4 1500 34
200 15.5 900 15.2 1600 33
300 6.8 1000 9.5 1700 37
400 3.9 1100 32 1800 40
500 4 1200 22 >1900 40
600 2 1300 29
700 8.2 1400 30
Table 2: Maximum voltage ripple (Uripp) vs Frequency in GSM & DCS
