WaveForm QuadMini Duo - Connecting Your System

Once you’ve identied the best position for your QuadMinis, it’s time to hook everything up.
Don’t drill any holes in your walls yet! Start with a temporary install and test performance rst.
Keep both QuadMinis at the position you’ve identied, but move your router indoors and
perform a nal round of tests to make sure everything is performing optimally.
If you purchased your QuadMini Duo as a complete kit, follow the steps below to assemble
and install your kit. If you only purchased the antennas, your assembly may look a little different.
Getting the Complete Kit Set Up
Refer to the diagram to the right as needed.
1 Place both QuadMinis near the best position you found in section 2 or 3. Don’t mount
them just yet!
2 Connect each QuadMini to each one of your UltraFlex-Quad cables and run the cables
into your building.
If you don’t want to drill holes into your walls or roof to route your cables, install your
Coax Window Entry cables in a window, and connect it to each QuadMini and/or
UltraFlex-Quad cables.
3 Connect your cables to your router’s cellular antenna ports and hand-tighten.
If your cellular router only has internal U.FL ports, install the included U.FL pigtail
adapters, and connect them to your UltraFlex-Quad cables.
4 Restart your cellular router, wait for it to reconnect, then perform 1-2 speed tests to
verify that you are happy with your system’s performance.
05
Connecting Your System
• Before attempting to route the cables through your building, lay each UltraFlex-Quad cable out at to
straighten it. This will make it easier to work with.
• A nger-tight connection is sufcient to secure the connectors. Tools are not required to tighten them
and may cause damage.
• Unsure how your cables connect to your router? Refer to your router’s manual, our device-specic guides
at waveform.com/hotspot-guides, or reach out to us for assistance.
Install Tips
