> Having difculties connecting your U.FL pigtails to internal antenna connectors? U.FL
connectors are small and can be difcult to install on the rst try. We suggest that you use a
tweezer to hold the cable in place and a pencil eraser to push the U.FL connector down.
> Does your cellular router need different adapters for its cellular antenna ports? If so, please
reach out to our team so we can help you obtain the parts you need.
Need Help with Adapters?
07
Some Final Tips
09
> Don’t judge your signal by signal strength or quality alone.
You may nd that your RSRP signal strength and SINR/RSRQ haven’t improved much, but
that your data rates are meaningfully better. There’s much more to an antenna than just gain:
our antennas are optimized for MIMO isolation to get you the best 5G data rates possible.
> If data rates decrease over time, consider re-optimizing your system.
Occasionally carriers will update their towers to broadcast different bands, light up new
towers, or simply turn off existing towers altogether. If your data rates get worse, try
repositioning and reaiming your QuadPro to get the best results.
Have Line of Sight with Your Cell Tower?
08
If you have direct line of sight to your nearest cell tower,
the four individual log periodic antennas in our 4x4 MIMO
Log Periodic Antenna Kit, may provide you with superior
performance over the QuadPro:
» For large buildings/hills/mountains/etc., you’d
mount its four antennas horizontally side-by-side.
» For large elds/plains/etc., you’d mount its four
antennas vertically top-to-bottom.
4x4 MIMO Log Periodic Kit
waveform.com/4x4-LP-kit
