Motor Driver HAT
2
/
16
S
P
E
C
I
F
I
C
A
T
I
O
N
S
Operating voltage:
6V~12V (VIN port)
Logic voltage:
3.3V
PWM controller:
PCA9685
Interface:
I
2C
Motor controller:
TBA6612FNG
Dimension:
65mm x 30mm
Holes size:
3.0mm
I
N
T
E
R
F
A
C
E
S
1
3
