In this chapter
Working with Screw Terminal Blocks
RS-485 Communication
RS-232 Communication
3
You are now ready to begin adding Click modules to your cabinet. For information on the
unique features of each of the devices in the Click line, see the corresponding chapter in
Part II of this document (or of the Click 500 Series User Guide).
Despite having dierent features, there are certain elements that are similar across devices.
Some of these, such as DIN rail mounting and the use of a T-bus for power and communi-
cation, have already been discussed. is chapter will discuss another such element: wiring
communication through the screw terminals.
Working with Screw Terminal Blocks
Many Click devices feature screw terminal blocks for wiring connections. ese screw ter-
minal blocks simplify wiring because they can be removed from the Click device, then
wired and reinserted.
To remove a screw terminal block, insert a small, thin item, such as a small screwdriver, into
the gap between the screw terminal block and the Click device (just above the screw heads)
and gently pry the two apart.
Aer wiring, simply reinsert the screw terminal block and push until it snaps into place. e
screw terminal blocks are red-keyed, meaning they will only plug into their specic jacks.
Wiring the Devices 3
