Wavetronix Click 222 - Default Chapter; Table of Contents

Contents
Introduction 7
Using this Manual 7
Part I Introduction to the Click Series
Chapter 1 The Power Plant 11
Connecting to a Circuit Breaker 12 • Connecting AC Surge
Protection 12 • Connecting Power 13 • Wiring AC Power into
the Click 201/202/204 14
Chapter 2 T-bus Basics 17
Adding a T-bus to the DIN Rail 18 • Mounting Click Devices
18 • Wiring T-buses 18
Chapter 3 Wiring the Devices 21
Working with Screw Terminal Blocks 21 • RS-485 Communi-
cation 22 • RS-232 Communication 24
Chapter 4 Installing Click Supervisor 27
Installing Click Supervisor 28 • Microso .NET Framework 31
Chapter 5 Using Click Supervisor 33
Connecting to Your Computer 33 • Accessing the Communi-
cation Screen 34 • Serial Communication 35 • IP Communica-
tion 37 • Working with Modules 38
Part II Individual Click 100–400 Series Modules
