Wayne-Dalton 8500 - Door Section Identification and Parts; Door Section Identification Chart

1/4”-20 x 7/8” Self
drilling screws (as required)
1/4”-20 x 11/16”
Self drilling screws
(RED HEAD) (as required)
Bottom
weather Seal
5/16” x 1-1/4”
Clevis pin (as required)
3/8” - 16 x 1-1/4”
Hex head bolts (as required)
Cotter pin (as required)
5/16”-18 x 3/4”
Carriage bolts (as required)
1/4”-20 x 9/16”
Track bolts (as required)
3/8”- 16 Hex nuts
(as required)
1/4” - 20 Hex
nuts (lift handles)
5/16”-18 Hex
nuts (as required)
5/16”-18 x 1/2”
Carriage
bolts (as required)
1/4”-20 x 11/16” Self
drilling screws (as required)
(2) 3/8”-16 x 3/4”
Truss head bolts
1/4”- 20 Flanged
hex nuts (as required)
5/16”-18 Flange
hex nuts (as required
)
1/4” - 20 x 2-1/2” Carriage bolts (as required)
(2) #8 x 1-5/8”
Self tapping screws (step plate)
#8 x 1” Pan head screws
(as required)
Clevis pin
(as required)
Cotter ring
(as required)
5/16” x 1-5/8” Hex head lag screws
(as required)
Door Section Identification
Section Quantity 3 and 4
6’0”
Type Of Sections
Intermediate(s) Section
I
6’0”
6’6”
6’3”
7’0”
6’9”
7’3”
7’3”
18”
21”
18”
24”
21”
21”
21”
18”21”
21”
24”
Not Available
21”
24”
24”
21”
Lock TopBottom
Door
Height
18”
8’0” 24”
7’9” 24” 21” 24”
7’9” 24” 21”
7’6” 24” 21” 24”
Section Quantity 5
7’9”
Type Of Sections
Intermediate Sections
7’6”
8’0” 18”
18”21”
18”
21”
II
I
LockBottom
Door
Height
Top
21”
When installing your door you must use sections of the appropriate height in the right stack-
ing order. What sections heights you need to use in what order depends on the height of your
door.
Unless your door is six sections in height, you will not receive an Intermediate III section.
The BOTTOM SECTION can be identified by the factory attached bottom bracket warning
labels on each end stile.
The INTERMEDIATE I SECTION may have a warning label attached to either right or left
hand end stile of the section. This section is always the 3rd section from the bottom of the
door.
Intermediate I section
Section
height
Bottom corner bracket warning labels
Bottom section
Warning labels
Section side view
Tools Required
Power drill Socket driver: 7/16” Level
Drill bits: 1/8”, 3/16”,
9/32”, 7/16”, 1/2”
Ratchet wrench Tape measure Pliers / Wire cutters Flat tip screwdriver
Phillips head screwdrive
r
Wrenches: 3/8”, 7/16”,
1/2”, 9/16”, 5/8”
3” Ratchet
extension
Sockets: 7/16”,
1/2”, 9/16”, 5/8”
Vise clamps Hammer Step ladder PencilLeather gloves
Locking pliersSafety glasses
Approved winding bars
Saw horses
