Wayne DW-10 - Internal Components; Setting the Paper Width Adjust Lever

2.4 Internal Components
* With power on, the paper feeds automatically when inserted into the paper inlet.
2.5 Setting the Paper Width Adjust Lever
The printer is set to 60mm paper width when shipping. Wayne supplied paper is 60mm.
If the 58 mm paper width is used, adjust the paper width lever as shown below.
Auto cutter
Paper supporter
Chute Access Door
Paper width adjust lever
*Paper manual
Feed Gear
Paper Inlet
Paper holder
Paper width adjust lever
Head up lever
_____________________________________________________________________________________7
P/N 000-920921- Rev 0D 04/2015
