INSTALLING LIGHT
1. Assemble Thread Stand by attaching parts as shown
(Figure 16).
2. Screw Thread Stand to Sewing Machine Stand using
the pre-drilled hole (Figure 17).
Figure 17
Figure 18
1. Pull light through hole behind sewing
machine head; wrap (Figure 18).
2. Attach magnetic light to machine and plug
into servo motor.
Figure 16
SETTING UP THE THREAD STAND
