Dual Top Evo 6 / 7 / 8 3 Technical data
302
Table 302 Technical Data - Dual Top Evo 7/8
Heater Operation Dual Top Evo 7 Dual Top Evo 8
Type approval
heater:
EMC:
e1 00 0195
e1 03 5000
Model Air heater with evaporator burner and electric
heater
Heat output
diesel
electric
Control range 1.5 to 6.0 kW
0.6 / 1.2 kW
1.5 to 6.0 kW
1.0 / 2.0 kW
Fuel Diesel, DIN EN 590
Fuel consumption Control range 0.19 to 0.66 l/h
Rated voltage 12 V
Operating voltage range 10.5 to 15 V
Current input at 12 V Summer mode
Winter mode, heating
and hot water
Stand-by
< 1 A
0.5 to 7 A
0,001 A
Rated power consumption Control range 15 to 65 W (EN 1646)
Max. ambient temperature:
Heater:
- Operation
- Storage
control panel:
- Operation
- Storage
-30 to +50 °C
-40 to +85 °C
-30 to +75 °C
-40 to +85 °C
Max. altitude
(guaranteed function)
2,200 m
Adjustment range for interior
temperature
Control range +5 to +35 °C
Delivery rate for hot air (free blowing
without cold and hot air ducting)
Maximum > 230 m
3
/h
CO
2
in exhaust gas (permitted function
range)
2 kW
6 kW
5.0 to 8.0
9.0 to 13
Water capacity 11 l
Water system pressure max. 3,5 bar
Overpressure valve 4.0 bar
Pressure water pump, central water
supply
Maximum 2.5 bar
Heater dimensions Length: 530 ± 2 mm
Width: 352 ± 1 mm
Height: 256 ± 1 mm
Weight (w/o water contents) 21 kg
