3 Technical data Dual Top Evo 6 / 7 / 8
301
3Technical data
Except where limit values are specified, the technical data
refer to the usual heater tolerances of ± 10 % at an ambient
temperature of + 20 °C and at the rated voltage and in rated
conditions.
Fuel for Dual Top
The diesel fuel DIN EN 590 specified by the manufacturer
must be used. Class EL heating oil, L heating oil or PME (bio-
diesel) must not be used.
Fuel additives have no negative influences on the heater.
If fuel is extracted from the vehicle‘s tank, follow the additive
instructions issued by the vehicle manufacturer.
After changing to low-temperature fuel, the heater must be
operated for approx. 15 minutes so that the fuel system is
filled with the new fuel.
Table 301 Technical Data - Dual Top Evo 6
Heater Operation Dual Top Evo 6
Type approval
heater:
EMC:
e1 00 0195
e1 03 5000
Model Air heater with evaporator burner
Heat output
diesel
electric
Control range 1.5 to 6.0 kW
-
Fuel Diesel, DIN EN 590
Fuel consumption Control range 0.19 to 0.66 l/h
Rated voltage 12 V
Operating voltage range 10.5 to 15 V
Current input at 12 V Summer mode
Winter mode, heating
and hot water
Stand-by
< 1 A
0.5 to 7 A
0.001 A
Rated power consumption Control range 15 to 65 W (EN 1646)
Max. ambient temperature:
Heater:
- Operation
- Storage
control panel:
- Operation
- Storage
-30 to +50 °C
-40 to +85 °C
-30 to +75 °C
-40 to +85 °C
Max. altitude
(guaranteed function)
2,200 m
Adjustment range for interior temperature Control range +5 to +35 °C
Delivery rate for hot air (free blowing without cold
and hot air ducting)
Maximum > 230 m
3
/h
CO
2
in exhaust gas (permitted function range) 2 kW
6 kW
5.0 to 8.0
9.0 to 13
Water capacity 11 l
Water system pressure max. 3,5 bar
Overpressure valve 4.0 bar
Pressure water pump, central water supply Maximum 2.5 bar
Heater dimensions Length: 530 ± 2 mm
Width: 352 ± 1 mm
Height: 256 ± 1 mm
Weight (w/o water contents) 20 kg
