Dual Top Evo 6 / 7 / 8 1 Introduction
101
1Introduction
1.1 Contents and purpose
This workshop manual is designed to assist trained personnel
with repairing the Dual Top integrated heaters.
1.1.1 Use of the integrated heaters
The Webasto Dual Top integrated air / water heaters are
designed to heat and to provide hot water in motor homes
and similar vehicles.
The heaters operate independently of the vehicle engine and
are connected to the fuel tanks and the service battery of the
vehicle.
The heaters are not designed for heating vehicles
transporting hazardous substances.
1.2 Meaning of signal words
Throughout this manual, the signal words CAUTION,
IMPORTANT and NOTE have the following meanings:
CAUTION
This heading is used to highlight operating instructions or
procedures which, if not or not correctly followed, may result
in personal injury or fatal accidents.
IMPORTANT
This heading is used to highlight operating instructions or
procedures which, if not or not correctly followed, may result
in damage to the equipment or its components.
NOTE
This heading is used to direct your attention to a special
feature deemed essential to highlight.
1.3 Additional documentation to be used
This workshop manual contains most of the information and
instructions required for repairing the Dual Top integrated
heaters.
However, it is necessary to heed additional documentation.
The operating / installation instructions and the installation
suggestion for the specific vehicle (if available) shall also be
used.
1.4 Statutory regulations and safety
instructions
In principle, the general accident prevention regulations and
current works safety instructions are applicable. The "General
safety regulations" that go beyond the scope of the above
regulations are stated below.
Any special safety regulations relevant to this instruction
manual will be highlighted in the relevant sections or text
passages of the procedures.
1.4.1 Statutory regulations governing
installation
The Dual Top heaters have been type-tested and approved in
accordance with EC Directives 72/245/EEC (EMC) and 2001/
56/EC (heater) with the following ECE permit numbers:
e1 00 0195
e1 03 5000
Installation is governed above all by the provisions in Annex
VII of Directive 2001/56/EC and the regulations in the
installation instructions.
Installation of the Dual Top Evo 7/8 heater and related com-
ponents must be in accordance with IEC 60364 (“Electrical in-
stallations in caravan parks and caravans”).
NOTE:
The provisions of these Directives are binding
within the territory governed by EU Directive 70/
156/EEC and/or 2007/46/EC should similarly be
observed in countries without specific regulations.
IMPORTANT:
Dual Top Evo 7/8: you have to be certified to work
on 230 V electric systems. Installation and all other
jobs carried out by none certified persons can
cause personal injury to you, the Dual Top and the
vehicle. In that case, Webasto will refuse all
liability.
IMPORTANT:
Failure to follow the installation instructions and
the notes contained therein will lead to all liability
being refused by Webasto. The same applies if
repairs are carried out incorrectly or with the use
of parts other than genuine spare parts. This will
result in the heater's type approval being voided,
and therefore also of the General Homologation/
ECE Type Approval.
NOTE:
Country-specific registration regulations must be
complied with.
