Webasto DVS300 - Page 38

Intelligent Fast-Charging System
GSE O&M for DVS300 / 330 / 330 IP55 / 400 and MVS330/400
31504-03-0101 Webasto Charging Systems, Inc.38
Fault or
Warning
Code
Fault or Warning Message Description
Action
Code
137 BMID BAT Over-Temp The battery temperature is too high. H
138 BMID Comm Fail Port A
The BMID link was lost after the
charge started.
F
139 BMID Cong Warning on Port A
The BMID is not adequately congured for
charger (power station) usage.
M
142 BMID Temp Sensor Failure on Port A
The BMID temperature sensor is out of
valid range.
G
143 Vbat Mismatch on Port A
The BMID and terminal voltages do not
match.
KK
144 Battery Over-discharged on Port A The battery is excessively discharged. K
145 Early Charge Termination on Port A The charge unexpectedly terminated. BB
164 Invalid Pilot on Port B
The battery was connected with an invalid
pilot circuit.
MM
165 Chrg VDC Port B Low
The battery voltage is too low for the charger
(power station).
Z
166 Chrg VDC Port B High
The battery voltage is too high for the charger
(power station).
Z
167 BMID B Vbat Too Low The battery voltage is too low for the BMID. L
168 BMID VDC Too High The battery voltage is too high for the BMID. L
169 BMID BAT Over-Temp The battery temperature is too high. H
