Webasto Thermo 90 ST Installation Manual

Foreword
www.webasto.us Webasto Product N.A., Inc. www.techwebasto.com
6
Symbol Identification
The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of
symbols and signal words which are intended to convey the level of importance of the safety messages. The progression of
symbols is described below. Remember that safety messages by themselves do not eliminate danger and are not a
substitute for proper accident prevention measures.
Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
MAY result in minor or moderate injury or property damage.
It may also be used to alert against unsafe practices.
These symbols are used to alert the installer to important or useful information about proper
installation of the equipment.
Heater Dimensions
DANGER
WARNING
CAUTION
OR
381
==
99
89
45
20ø
5ø
39ø
92
152
88
95
30ø
38ø
20ø
352
131
49
99
137
100
1. Combustion Air Intake
2. Exhaust Fume Outlet
3. Fuel Intake
4. Coolant Inlet
5. Coolant Outlet
Fig. 1 Dimensions of the Thermo 90 ST
12
3
5
4

Webasto Thermo 90 ST Specifications

General

Heating Capacity	9 kW
Weight	4.8 kg
Dimensions	254 x 100 x 177 mm
Fuel	Diesel
Nominal Voltage	12V or 24V
Heating Power	9 kW
Voltage	12V or 24V
