Marine heating system Installation Instructions
16 © Webasto Global Comfort Solutions
®
• Fit the metering pump close to the tank. Distance from the tank take-off is ≤ 1.2 m.
• Install the pump in a dry/cool area. Do not install in the bilge.
• Pay attention to the pump flow direction.
• Use flexible mountings for the metering pump (reduces the transmission of impeller
noise/ticking).
• Recommended installation: suspended from solid boat structures.
• Recommended fuel line mounting: Distance from metering pump ≥ 20cm or in an elbow
so that no impeller noise is conducted through the pipes.
Fuel line mounting at wall (top view) should not be too close to the metering pump
• Attach the metering pump horizontally.
Assembly orientation of the metering pump
If the metering pump has a plastic fuel damper, if it is installed in the engine compartment it must
be protected with a protective sleeve (see parts catalog).
