3
VW Passat
Heater Unit/Installation Kit
Also required:
and/or
Other required tools:
Attention
No heater control is included in the delivery scope. The desired heater control must be ordered
separately.
Foreword
These installation instructions apply to VW Passat Diesel vehicles with an auxiliary heater installed as
standard equipment
- For the validity, see page 2 - from model year 2005 and later, assuming technical modifications to the
vehicle do not affect installation, any liability claims excluded. Depending on the vehicle version and
equipment, modifications may be necessary during installation with respect to these installation
instructions.
However, the stipulations in the "installation instructions" and "operating and maintenance instructions"
for the Thermo Top C/P/E must always be observed.
The corresponding rules of technology and any information from the vehicle manufacturer should be
observed during the installation work.
General Instructions
Installation should be carried out according to the general, standard rules of technology. Unless
specified otherwise, fasten hoses, lines and wiring harnesses to original vehicle lines and wiring
harnesses using cable ties.
Sharp edges should be fitted with edge protectors (split-open plastic hose).
Spray unfinished body areas, e.g. drilled holes, with anti-corrosion wax (Tectyl 100K, Order No.
111329).
Special Tools
- Computer with MS Windows operating system
- Webasto diagnosis adapter
Quantity Description Order No.:
1 Upgrade kit for VW Passat Climatronic 9013729E
1 Upgrade kit for VW Passat Climatic 9013728D
1 Digital timer kit 1301122C
1 Telestart T80 advanced kit 9007098A
Vehicle Heater unit
PC USB diagnosis 9009064C
Upgrade kit for Touran 9008996A
