Thermo Top E and Z/C 4 Technical Data
401
4 Technical Data
4.1 Thermo Top E
Where no threshold values are specified technical data in
the table are understood to include standard tolerances
for heater units of ± 10 % at an ambient temperature of
+ 20° C.
All electrical components are selected for a nominal
voltage of 12 Volts.
Propellant for Thermo Top E (Fuel):
The proper fuel is the fuel specified by the vehicle
manufacturer.
Propellant for Thermo Top E (Diesel):
The proper Diesel fuel is the one specified by the vehicle
manufacturer. When switching to low temperature
propellants the heater must be operated for at least
15 minutes to prime the fuel pipe and pump with the new
type of fuel.
A persistent influence by additives is not known.
*) Operation only permitted with mixture Diesel/PME with PME quantity < 50 %.
Heater Operation Thermo Top E - B Thermo Top E - D Thermo Top E - D
Mark of conformity ~ S316 ~ S317
Type Water heater with evaporator burner
Heating flow Full load
Part load
4.0 kW
2.5 kW
Fuel Fuel Diesel Diesel/PME*
Fuel consumption Full load
Part load
0.54 l/h
0.34 l/h
0.47 l/h
0.30 l/h
Nominal voltage 12 V
Operating voltage range 10.5 ... 15 V
Nominal power consumption without
circulation pump (without vehicle air fan)
Full load
Part load
22 W
18 W
Permissible ambient temperature:
Heater: – operation
– storage
Dosing pump: – operation
–40° C ... + 60° C
–40° C ... +120° C
–40° C ... + 20° C
–20° C ... + 60° C
–40° C ... +120° C
–20° C*... + 20° C
Permissible operating overpressure
(heat carrier)
0.4 ... 2.5 bar
Heat exchanger capacity 0.15 l
Minimum coolout circuit capacity 3.00 l
Minimum volume flow for the heater 250 l/h
CO
2
in exhaust (permissible functional range) 8 ... 12 Vol.-%
Dimensions of heater length 214 mm
width 106 mm
height 168 mm
Weight 2.9 kg
Circulation pump 4847
Volume flow against 0.1 bar 900 l/h
Nominal voltage 12 V
Operating voltage range 10.5 ... 15 V
Nominal power consumption 14 W
Dimensions of circulation pump length 95 mm
width 61 mm
height 61 mm
Weight 0.3 kg
