Webb WELT26 - Parts List; Engine Parts List

INSTRUCTION MANUAL
PARTS DIAGRAM - WELT26 Engine
PARTS LIST - WELT26 Engine
Item No. Part No. Description Qty
Item No. Part No. Description Qty
1 WE03010110121 Screw M5x12 1
32 WE70070030026 Cover 1
2 WE70030030853 Engine Cowling 1
33 WE70030030164 Guide 1
3 WE03020020055
Screw GB/T9074.4
M4x12
1
34 WE03040020012 Washer GB/T97.1 4 2
4 WE03010010062 Screw M5x20 4
35 WE02070010048 Spacer 2
5 WE70070130069 Cylinder 1
36 WE02050030229 Ignition Coil 1
6 WE03130010013 Spark Plug RCJ6Y 1
37 WE03020020054 Bolt GB/T9074.4 M4*20 2
7 WE02070010032 Cylinder Gasket 1
38 WE02050050213 Electrical Connections 1
8 WE02020020003 Piston Ring 2
39 WE02080030042 Rubber 1
9 WE02010020005 Piston 1
40 WE02070010162 Exhaust Gasket 1
10 WE02020150002 Stop Ring 2
41 WE02050010138 Exhaust 1
11 WE02020010004 Piston Pin 1
42 WE03050010008 Washer GB/T93 8 1
12 WE02020030017 Piston Pin Retainer 2
43 WE03040020018 Washer GB/T97.1 8 1
13 WE03090020018 Needle Bearing 1
44 WE03010010077 Bolt M5x55 2
14 WE02020120023 Crankshaft 1
45 WE02070010019 Side Gasket 1
15 WE03090010028
Bearing GB/T276
6001/P5
2
46 WE70030020016 Insulator 1
16 WE03100010009 Seal 12x22x7 2
47 WE03020020012 Bolt GB/T9074.4 M5*20 6
17 WE03060010002 Pin 4
48 WE02070010071 Carburettor Gasket 1
18 WE70070050038 Rear Crankcase 1
49 WE02050020101 Carburettor 1
19 WE02050100015 Starter Pawl 1
50 WE70080120007
Air Filter Housing with
Choke
1
20 WE02050070090 Recoil Assembly 1
51 WE03020020044 Bolt GB/T9074.4 M5*55 2
21 WE03020020029
Screw GB/T9074.4
M4*16
5
52 WE02090010011 Air Filter 1
22 WE03070010001
Woodruff Key
3x3.7x12
1
53 WE70030040225 Air Filter Cover 1
23 WE02070010119 Crankcase Gasket 1
54 WE02110030079 Air Filter Screw 1
24 WE70070050039 Front Crankcase 1
55 WE02110020026 Fuel Tank Cap Assembly 1
25 WE03010010058 Bolt M5x25 4
56 WE61330010017 Fuel Inlet Pipe 1
26 WE02050030020 Flywheel 1
57 WE61330010018 Fuel Outlet Pipe 1
27 WE03030020003 Nut M8 1
58 WE02050120002 Fuel Filter 1
28 WE03040050052
Washer
φ6*15*1.2
2
59 WE03020020027
Screw GB/T9074.4
M5*16
3
29 WE02050160002 Clutch Assembly 1
60 WE03040050022 Washer φ5*15*1 3
30 WE03040050042 Washer 2
61 WE70050030170 Fuel Tank 1
31 WE02020130001 Clutch Bolt 2
