Webb WER18SP - Blade Assembly Parts List

PARTS DIAGRAM AND LIST – BLADE ASSEMBLY
Item No Part Number Description Qty
1 WE114-18 Blade Adapter Assy 1
2 WE113-69 18" Double Edge Blade 1
3 WE113-70 Blade Washer 1
4 WE113-71 50mm Hex Flange Bolt 1
5 WE114-19 Chassis Bushing 2
6 WE114-20 Hex Self-Tapping Screw 3/8-16x1ST-30mm 2
7 WE114-21 Hex Self-Tapping Screw 3/8-16x1ST 1
8 WE114-22 Belt Cover 1
