Webb WER460SP - Page 27

27
PARTS DIAGRAM - DVO140
PARTS LIST - DVO140 - PT 1
Item No
Webb Part No.
Webb Description
Qty
1
WE151-91365
M6x12 Bolt
7
2
WE151-311101
Cylinder Head Cover
1
3
WE151-96161
Cylinder Gasket
1
4
WE151-312101
Rocker Arm
2
5
WE151-312201
Push Rod Guide Plate
1
6
WE151-311802
Valve Spring Seat
2
7
WE151-316001
Valve Spring
2
8
WE151-311801
Intake Valve Returner
2
9
WE151-311701
Intake Valve
1
10
WE151-315901
Exhaust Valve
1
11
WE151-97109
Spark Plug
1
12
WE151-316302
Recoil Housing
1
13
WE151-91369
M6x25 Bolt
1
14
WE151-313701
Muffler Assembly
1
15
WE151-314302
Governor Plate
1
16
WE151-311901
Push Rod
2
17
WE151-316101
Valve Lifter
2
18
WE155-312003
Camshaft Assembly
1
19
WE151-311602
Piston Ring Set
1
20
WE155-311202
Piston
1
21
WE155-315502
Piston Pin
1
22
WE151-291301
Piston Clip
2
23
WE151-311501
Connecting Rod Assembly
1
24
WE151-310202
Cylinder
1
25
WE155-93517
Oil Seal
1
26
WE155-90030
M6 Flange Nut
3
27
WE151-91829
Rocker Arm Adjuster
2
28
WE151-310505
Deflector
1
29
WE155-315201
Brake Assembly
1
30
WE151-300605
Circular Plate
1
31
WE151-310606
Breather Valve Spring
1
32
WE151-91038
Stud Bolt
2
33
WE151-293601-055
Fuel Cap Assembly
1
34
WE151-293206-055
Fuel Tank
1
35
WE151-300505
Deflector
1
36
WE151-92007
M4x8 Screw
1
37
WE151-91370
M6x16 Bolt
3
38
WE151-299901
Fuel Filter
1
39
WE151-94403
Fuel Pipe Clamp Ф7.5
1
40
WE151-95457
Fuel Pipe
1
41
WE151-313901
Governor Arm Shaft
1
42
WE151-96808
Governor Arm Shaft Washer
1
43
WE151-93520
Governor Arm Shaft Seal
1
44
WE151-243902
Lock Pin
1
45
WE151-314001
Governor Arm
1
PARTS LIST - DVO140 - PT 2
Item
No
Webb Part No. Webb Description Qty
46
WE151-91066
Recoil Stud Bolt 2
1
47
WE155-90016
M6 Nut
2
48
WE155-312701
Governor Rod
1
49
WE155-314201
Throttle Return Spring
1
50
WE155-314102
Governor Spring
1
51
WE151-90036
Nut
2
52
WE155-314401
Upper Shroud Assembly
1
53
WE151-95626
Breather Tube
1
54
WE155-210801
Q-Type Line Card
1
55
WE155-310305
Crankshaft
1
56
WE151-90037
Nut
2
57
WE151-94225
Crankshaft Washer
1
58
WE151-314303
Governor Assembly
1
59
WE151-96162
Breather Chamber Gasket
1
60
WE151-310602
Breather Chamber Cap
1
61
WE151-310901
Dowel Pin
2
62
WE151-310102
Crankcase Cover Assembly
1
63
WE151-93523
Oil Seal
1
64
WE151-91366
M6x18 Bolt
6
65
WE151-91367
M6x45 Bolt
2
66
WE155-95904
Tube
1
67
WE151-94415
Fuel Pipe Clip
3
68
WE151-315601-138
Dipstick
1
69
WE151-90038
M6 Nut
2
70
WE151-310608
Breather Filter
1
71
WE155-97566
Ignition Coil Assembly
1
72
WE151-91064
Ignition Coil Stud Bolt
1
73
WE151-91065
Recoil Stud Bolt 1
1
74
WE155-310403
Flywheel Assembly
1
75
WE151-304602
Recoil Starter Fan
1
76
WE151-304501
Starter Pulley
1
77
WE151-90003
Nut
1
78
WE155-292506
Muffler Shield
1
79
WE152-96130
Air Filter Gasket
1
80
WE155-312901
Air Filter Assembly
1
81
WE151-91039
Stud Bolt
2
82
WE151-96128
Intake Gasket
1
83
WE151-312301
Carburettor Insulator
1
84
WE151-96129
Carburettor Gasket
1
85
WE155-312802
Carburettor Assembly
1
86
WE155-96168
Exhaust Gasket
1
87
WE151-294909-053
Engine Cover
1
88
WE155-294802-053
Recoil Assembly
1
89
WE151-91816
Drain Bolt
1
90
WE151-94007
Drain Bolt Washer
1
