Webb WER460SP - Page 29

29
PARTS DIAGRAM - WER460SP (1938220001)
PARTS LIST - WER460SP (1938220001) - PT 1
Item
No
Webb Part No. Webb Description Qty
1
WE153-91221
Bolt 3/8-24UNFX38
1
2 WE153-94042 Flat Washer 1
3
WE153-602001 Blade Washer 1
4
WE158-602002
Blade (460mm)
1
5
WE153-602003
Blade Adapter
1
6
WE158-602004
Blade Adapter Bush
1
7 WE153-296510 Key 1
8
WE154-91304
Bolt M6x16
2
9 WE158-606109 Belt Cover 1
10
WE153-90060 Nut M6 14
11
WE154-606011
Pulley
1
12
WE154-91405
Bolt M6x8
1
13
WE158-606088
Belt VZ762
1
14 WE154-92139 Screw KAL50x12 11
15
WE154-296501 Key 1
16
WE158-601168-333
Cutting Deck
1
17
WE154-606003
Front Wheel Shaft Retaining Plate
2
18
WE154-92111
Bolt M6x14
8
19 WE158-91347 Bolt M8x30 3
20
WE149-94040
Spring Washer
3
21 WE149-94041 Washer 8.4x24x2 4
22
Engine DVO140 1
23
WE153-94036
Circlip Φ5
3
24
WE153-604016
Left Torsional Spring
1
25
WE158-604039
Rear Cover Axle
1
26 WE158-604090 Rear Cover 1
27
WE153-604045 Right Torsional Spring 1
28
WE154-606160
Nylon Collar
2
29
WE154-606009
Rear Wheel Shaft Retaining Plate
2
30
WE154-601005
Cable Bush
1
PARTS LIST - WER460SP (1938220001) - PT 2
Item No
Webb Part No.
Webb Description
Qty
31
WE158-604004
Deck Rear Panel
1
32
WE158-601004 Mulch Plug 1
33 WE149-90059 Nut M8 4
34
WE153-91868
Bolt M8x45
4
35
WE154-599601
Wire Harness Clip
1
36 WE158-91343 Bolt M8x16 4
37
WE158-601098
Left Handle Support
1
38 WE153-605003-198 Small Handle Knob 2
39
WE158-605005
Lower Handle
1
40
WE153-605221
Cable Clip
2
41 WE158-604108 Side Discharge Lock Spring 1
42
WE153-605008 Upper Handle (Come's with 45) 1
43
WE153-91870
Bolt M6x35
1
44
WE153-605010-136
OPC/Brake Lever
1
45
WE153-605007-053
Soft Grip (Come's with 42)
1
46 WE154-605015-136 Drive Lever 1
47
WE153-605009 Rope Guide Support 1
48
WE153-90016
Nut M6
1
49
WE149-94057
Washer Φ8.4*20*2
3
50
WE153-90061
Nut M6
2
51 WE158-604103 Side Discharge Lock 1
52
WE158-605058 Brake & Drive Cable Assembly 1
53
WE154-606016
Return Spring
1
54
WE158-601099
Right Handle Support
1
55
WE153-91404
Bolt M6x14
4
56 WE158-604102 Side Discharge Lock Buckle 1
57
WE158-604047-057 Collection Bag 1
58
WE158-604046-010
Collection Bag Frame
1
59
WE153-605002-198
Large Handle Knob
2
60
WE153-606007-198
Wheel Cover (8")
2
PARTS LIST - WER460SP (1938220001) - PT 3
Item No
Webb Part No.
Webb Description
Qty
61
WE154-606006
Wheel (8")
2
62
WE154-606008
Inner Wheel Cover (8")
2
63
WE158-604008
Side Discharge Chute
1
64
WE158-604001
Side Discharge Spring
1
65 WE158-604012 Side Discharge Bracket 1
66 WE158-604010 Side Discharge Axle 1
67 WE158-91406 Bolt M6x14 2
68 WE158-604009 Side Discharge Cover 1
69 WE149-90057 Nut M10x1.5 4
70 WE153-605006 Stem 2
71
WE153-94046
Flat Washer
4
72
WE158-606005
Front Axle
1
73
WE154-606004
Front Axle Hoop
2
74
WE153-606001-198
Wheel Cover ("7)
2
75
WE153-606002
Wheel (7")
2
76
WE154-94049
Circlip
4
77 WE154-606013 Right Drive Cog 1
78 WE153-603002 Height Adjuster Plate 1
79 WE153-603003-198 Height Adjuster Handle 1
80
WE158-606158
Rear Axle Assembly
1
81
WE153-90058
Nut M6
6
82
WE153-603037
Height Adjuster Lever
1
83
WE158-603004
Height Adjustment Bar
1
84
WE153-603062
Height Adjuster Spring
1
85
WE153-91867
Bolt
2
86
WE154-606012
Left Drive Cog
1
87
WE158-606083
Gearbox
1
88
WE158-606021
Gearbox Gear Pin
2
PARTS LIST - WER460SP (1938220001) - PT 3
Item No
Webb Part No.
Webb Description
Qty
61
WE154-606006
Wheel (8")
2
62
WE154-606008
Inner Wheel Cover (8")
2
63
WE158-604008
Side Discharge Chute
1
64
WE158-604001
Side Discharge Spring
1
65
WE158-604012
Side Discharge Bracket
1
66
WE158-604010
Side Discharge Axle
1
67
WE158-91406
Bolt M6x14
2
68
WE158-604009
Side Discharge Cover
1
69
WE149-90057
Nut M10x1.5
4
70
WE153-605006
Stem
2
71
WE153-94046
Flat Washer
4
72
WE158-606005
Front Axle
1
73
WE154-606004
Front Axle Hoop
2
74
WE153-606001-198
Wheel Cover ("7)
2
75
WE153-606002
Wheel (7")
2
76
WE154-94049
Circlip
4
77
WE154-606013
Right Drive Cog
1
78
WE153-603002
Height Adjuster Plate
1
79
WE153-603003-198
Height Adjuster Handle
1
80
WE158-606158
Rear Axle Assembly
1
81
WE153-90058
Nut M6
6
82
WE153-603037
Height Adjuster Lever
1
83
WE158-603004
Height Adjustment Bar
1
84
WE153-603062
Height Adjuster Spring
1
85 WE153-91867 Bolt 2
86 WE154-606012 Left Drive Cog 1
87 WE158-606083 Gearbox 1
88 WE158-606021 Gearbox Gear Pin 2
PARTS LIST - WER460SP (1938220001) - PT 3
Item No Webb Part No. Webb Description Qty
61
WE154-606006
Wheel (8")
2
62
WE154-606008
Inner Wheel Cover (8")
2
63
WE158-604008
Side Discharge Chute
1
64
WE158-604001
Side Discharge Spring
1
65
WE158-604012
Side Discharge Bracket
1
66
WE158-604010
Side Discharge Axle
1
67
WE158-91406
Bolt M6x14
2
68
WE158-604009
Side Discharge Cover
1
69
WE149-90057
Nut M10x1.5
4
70
WE153-605006
Stem
2
71
WE153-94046
Flat Washer
4
72
WE158-606005
Front Axle
1
73
WE154-606004
Front Axle Hoop
2
74
WE153-606001-198
Wheel Cover ("7)
2
75
WE153-606002
Wheel (7")
2
76
WE154-94049
Circlip
4
77
WE154-606013
Right Drive Cog
1
78
WE153-603002
Height Adjuster Plate
1
79
WE153-603003-198
Height Adjuster Handle
1
80
WE158-606158
Rear Axle Assembly
1
81
WE153-90058
Nut M6
6
82
WE153-603037
Height Adjuster Lever
1
83
WE158-603004
Height Adjustment Bar
1
84
WE153-603062
Height Adjuster Spring
1
85
WE153-91867
Bolt
2
86
WE154-606012
Left Drive Cog
1
87
WE158-606083
Gearbox
1
88
WE158-606021
Gearbox Gear Pin
2
