Weber mt CR 7 - Start Module (MS 15) Description

15
5
1
2
4
3
The start module
MS 15 (CR 7)
1 Operational status indicator
(LED)
This indicator signals that the ignition of the machine is
switched on. It comes on as soon as the key switch (5) is set
to position “1”.
2 Oil pressure indicator (LED) Thisindicatorwarnsofinsu󰀩cientoilpressure.
Shut down the machine immediately when this indicator comes
on.
3 Operating hours counter Thiseldshowstheoperatinghourscompletedbythe
machine.
The counter will show the remaining time until the next
scheduledmaintenancefortherst10secondsafterthe
ignition was switched on (key switch (5) in position “1”).
4 Charge level indicator (LED)
This indicator comes on if the charging current supply to the
starterbatteryisinsu󰀩cient.Whileoperationofthemachine
canresume,thecauseoftheinsu󰀩cientchargingcurrent
supplymustbeidentiedandrectied.
5 Key switch The key switch is used to switch the power supply (ignition) to
themachineonoro󰀨.Italsoactuatestheelectricstarterofthe
engine.
Switch in position “1”
The ignition is switched on.
Switch in position “0”
Theignitionisswitchedo󰀨.
Switch in position “2”
The electric starter is actuated.
ATTENTION
Danger of material damage from running electric starter.
The ignition key must spring back from position “2” to position
“1”. Otherwise:
Shut down the machine immediately.
Figure 2
