Weber mt CR 7 - Start Module (MS 25;35) Description

16
1
2
3
4
5
6
7
8
MS 25 & 35 (CR 7 MDM & CCD)
1 Operational status indicator
(LED)
This indicator signals that the ignition of the machine is
switched on. It comes on as soon as the key switch (5) is set
to position “1”.
2 Oil pressure indicator (LED) Thisindicatorwarnsofinsu󰀩cientoilpressure.
Shut down the machine immediately when this indicator comes
on.Theengineisswitchedo󰀨automatically.
3 Charge level indicator (LED) This indicator comes on if the charging current supply to the
starterbatteryisinsu󰀩cient.Whileoperationofthemachine
canresume,thecauseoftheinsu󰀩cientchargingcurrent
supplymustbeidentiedandrectied.
4 Operating hours counter Thiseldshowstheoperatinghourscompletedbythe
machine.
The counter will show the remaining time until the next
scheduledmaintenancefortherst10secondsafterthe
ignition was switched on (key switch (5) in position “1”).
5 Temperature indicator (LED) This indicator comes on if the engine is overheating.
Shut down the machine immediately when this indicator comes
on. The engine is shut down automatically 3 minutes after the
indicator comes on.
6 Air lter indicator (LED) Thisindicatorcomesonincaseofheavyfoulingoftheairlter.
Shut down the machine immediately when this indicator comes
on. The engine is shut down automatically 10 minutes after the
indicator comes on.
7 Maintenance indicator (LED) This indicator comes on 10 operating hours before the next
scheduled maintenance interval.
Figure 3
