Weber Performer 54787 - Exploded View List

WWW.WEbER.cOM
®
15
ExPlODED vIEW lISt
1. Lid
2. Hinged Cooking Grate
3. Charcoal Baskets
4. Charcoal Grate
5. One Touch™ Damper Assembly
6. Lid Holder & Lower Support Assembly
7. Ash Catcher Ring
8. Ash Catcher Handle
9. High-Capacity Ash Catcher
10. Axle
11. Leg Frame Bracket
12. Igniter Wire Stay
13. Wheel
14. Hub Cap
15. Wheel Cover
16. Front Panel
1 7. Logo Plate
18. Tool Holders
19. Gas Control Cover
20. Igniter
21. Lid Handle Assembly
22. Lid Damper Assembly
23. Thermometer Assembly
24. Bowl
25. Table
26. CharBin™ Retention Chain
2 7. Burner Assembly
28. Hose & Regulator with Orifice Clip
29. Rear Panel
30. Frame Leg
31. CharBin™ Hardware
32. CharBin™
33. Casters
34. Caster Inserts
35. Leg Frame Bracket Clamp
36. Bottom Rack
3 7. Matchlight Holder
MAY INCLUDE:
38. Sear Grate with Hinged Cooking Grate
