User’s Manual
SOR 3
9
13.0 Device Connections
In order to meet the EMI requirements, a shielded output cable to the conveyor must be used.
12
3 4
1
P
E
2
3
1
E
2
3
Main supply
110 / 230 V,
50/60 Hz
PE
3 4
1
1 = L
2 = N
3 = nc
4 = PE
1 = A1
2 = A2
3 = Screen
4 = PE
1
2 3
PE
Output Feeder
Enable input
3 = GND
4 = +24V input
2 1
43
2
4
1
3
14.0 Dimensional Diagram
Chassis dimensions SOR 3 (3A)
143
10
