Weber SRV 62 - 1 Technical Description; Illustration

6 SRV62_66
1. Technical Description
Figure 1 Overall View SRV
1 Fuel tank 6 Reversible starter (not shown)
2 Tank cap 7 4-stroke engine
3 Engine speed adjusting lever (not shown) 8 Tamping shoe
4 Handle 9 Bellow
5 Air filter 10 Upper tamper part
11 Lower tamper part
1.1 Illustration
1
2
4
5
7
8
9
11
10
