Correct handling of the quick-release nut and balance shaft
Note: Incorrect use of the quick-release nut or incorrect clamping and removal of
the wheel can damage the quick-release nut and the clamping shaft. The
manufacturer/importer/seller is not liable for damage caused by improper use.
This damage is not covered by the warranty.
Fastening and release of the wheel
•
When installing and removing the wheel, guide the rim evenly to the centering cone without touching the
clamping shaft as shown in Fig. 1.
•
Slide the quick-release nut by operating the mechanism to the edge of the rim. Do not use the mechanism for
tightening the quick-release nut but its handles.
Fig. 1 Fastening the wheel
•
Unscrew the quick-release nut until the rim is completely unscrewed, as shown in Fig. 2. Failure to do so may
result in damage to the quick-release nut and the clamping shaft.
•
When removing the wheel, take care not to damage the thread of the clamping shaft. Continue as shown in
Fig. 1.
Fig. 2
