9
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
connection
______
Step 3-B: Route & Connect
Inside Antenna To Booster
Inside
Antenna
30’ RG-6 Cable
Booster
Connect the white 30’ Cable to Inside Antenna and route to the
Home MultiRoom Booster and connect to the port labeled
‘INSIDE ANTENNA’.
The greater the separation, the better
the Booster performance
Outside
Antenna
Inside
Antenna
Cell
Tower
Booster
Cable Mounting Clips provided
