HOME ROOM CELL PHONE SIGNAL BOOSTER
______
Step 3: Route & Connect
Cable To System
Connect the white RG-6 Cable to Outside Antenna and route cable
into the home. All connections should be hand tightened only.
A Window Entry Cable is provided to help make cable entry easier. Route
cable to the Home Room booster and connect to top port
labeled ‘OUTSIDE’.
Outside
Antenna
Inside
Antenna
Outside
Antenna
Cell
Tower
Inside
Antenna
RG-6 Cable
RG-6 Cable
Window
Entry Cable
Booster
Window Entry Cable
Booster
