Owners Information
Name Of Dealer: Phone:
Address:
Pump Model No: GPM: Total Dynamic Head: (FT) Date Installed:
HP: Volts: Phase: HZ: Service Factor Amps:
AWG Cable Size: Ft.:
Well Diameter: (IN). Well Depth: (FT). Amount Of Casing: (FT).
Static Water Level: (FT). Well Drawdown: (FT). Pump Setting: (FT).
Pipe Size In Well: (IN). Length Of Pipe In Well: (FT).
Pipe Material: PVC: Galv.:
Pipe Size From Well To Discharge Point: (IN). Length Of Pipe From Well To Discharge Point: (FT).
Pipe Material: PVC: Galv.:
Pressure Tank: U.S. Gallons: Pressure Switch Setting Cut In PSI: Cut Out PSI:
Check Valves At: @: @: @: (FT).
Insulation Resistance: OHMS: OHMS: OHMS
Resistance Between Motor Leads - 3 Wire B/Y: OHMS B/R: OHMS Y/R: OHMS 2 Wire B/B: OHMS
Little Or No Liquid Delivered By Pump
Cause of Trouble Checking Procedure Correction Action
A. Faulty or incorrectly installed check valve. Inspect check valve. Is it installed backwards? Replace if defective.
B. Worn pump. Reduce pressure switch setting - If pump shuts off worn Pull pump & replace.
parts due to sand - usually present in tank - may be the
problem.
C. Pump bound by sand. Amp readings 3 to 6 times higher than normal will be Pull pump clean & reset depth or reverse rotation
indicated. Warning: Do not reverse rotation with a control
box containing a solid state switch or electronic
relay, failure will occur.
1 phase motor: 1 1/2 HP & up with voltage relay in
control box. Switch the red & black leads in the
control box. Turn on for 4 seconds, turn off for 1
minute, repeat 3 times.
3 Phase motor: interchange any 2 cable leads where
they connect to the lead terminals in the magnetic
starter. Turn on for 4 seconds, turn off for 1 minute,
repeat 3 times.
D. Incorrect motor rotation - 3 phase motor. Flow rate & pressure will be substantially reduced. For Interchange any 2 cable leads where they connect to
correct rotation the pump should jerk clockwise when the lead terminals in the magnetic starter.
looking into the pump discharge when started.
E. Well contains air or gases. Drain tank. With valve open, turn pump on, if air or Start and stop pump until a constant stream of water
gases are present in the water, flow will be intermittent. is delivered.
