● Then as shown in Fig. 3, insert the clearance gauge between No.
5 valve rocker arm piston and the exhaust valve rod end or valve rod cap.
By turning No. 2 regulating bolt, adjust the valve clearance to 0.25 mm.
Tighten check nut.
※
Caution: During
adjustment, turn No.
2 regulating bolt until
clearance gauge is
clamped so that No.
5 valve r o cker arm
piston is pressed to its
bottom. There is not
clearanc e betwe e n
No. 5 v alve ro c k e r
arm piston and the piston installation hole bottom plane in exhaust valve
rocker arm.
※
Tools
：
6# screwdriver and 14 mm double offset ring wrench
