12
Technical Data 12
293
[en] | 08/2022 | 1000441528 | 1190e | Operator’s Manual
12.7 Weights
12.7.1 Weight of the vehicle
The weight of the vehicle may vary due to different equip-
ment (e.g. when the tires are filled with water).
Designation
1)
Values in kg
2)
Values in kg
3)
Operating weight 2170 2350
Permissible total weight 2800 2800
Permissible axle load front 1300 1300
Permissible axle load rear 1800 1800
Tipping load with bucket loader unit horizontal,
vehicle straight
1550 1620
Tipping load with bucket loader unit horizontal,
vehicle bent
1210 1320
Payload with bucket (S= 2) 610 810
Tipping load with pallet fork loader unit horizontal,
vehicle straight
1110 1160
Tipping load with pallet fork loader unit horizontal,
vehicle bent
860 940
Bearing load with pallet fork (S = 1.25) 690 750
Bearing load with pallet fork (S = 1.67) 510 560
1) Payload and carrying load according to ISO 14397 – EN474-3
2) Vehicle with overhead guard
3) Vehicle with cab
Payload and bearing load
Specified payloads and bearing loads are values for the
vehicle with basic equipment. Payloads and bearing loads
change due to different vehicle configurations. Values
given are for the minimum vehicle performance.
The payloads and bearing loads are determined starting
from the "Tipping load with bucket loader unit horizontal,
vehicle bent".
The payload of the vehicle with bucket is determined as fol-
lows:
• The vehicle is on uneven and soft ground (conversion
factor S = 2).
The payloads of the vehicle with pallet fork are determined
using two values:
