M10 x 130mm Bolt (9)Ð1
M8 x 50mm Bolt (13)Ð2
M8 Washer (20)Ð25
M8 Nylon Locknut (39)Ð8
M8 x 60mm Bolt (43)Ð2
11mm x 7mm Spacer (23)Ð2
11mm x 10.5mm Spacer (44)Ð2
M8 x 50mm Carriage Bolt (45)Ð2
M10 x 75mm Bolt (46)Ð5
M10 x 60mm Bolt (47)Ð4
M10 x 70mm Bolt (48)Ð4
M10 x 50mm Bolt (49)Ð3
M8 x 40mm Screw (50)Ð8
M8 x 16mm Screw (51)Ð3
M10 Washer (53)Ð32
M10 Nylon Locknut (54)Ð15
M8 x 30mm Screw (60)Ð2
This chart is provided to help you identify the small
parts used in assembly. Important: Some parts may
have been pre-assembled for shipping purposes.
If you cannot find a part in the parts bags, check
to see if it has been pre-assembled. The number in
parenthesis below each part refers to the key number
of the part. The second number refers to the quantity
needed for assembly.
Part Identification Chart - Model No. WEBE14871
R0699A
To Next Page
