Weider 9900i - Page 25

25
44
44. Orient the Weight Selector (32) as shown.
Tighten the lower end of the Burn Cable (45)
c
ompletely into the Weight Selector (32).
I
nsert the threaded end of the High Cable (44)
through the upper end of the Burn Cable (45).
Tighten the High Cable (44) at least five com-
plete turns into the Weight Selector (32).
Tighten the Nut (A) against the Burn Cable (45).
Then, tighten the Nut (B) against the Weight
Selector (32).
45
44
32
45
B
A
45. Insert the Weight Selector (32) into the stack of
Weights (30).
Lift the top Weight (30) upward, and tap a Roll
Pin (37) into the Weight Selector (32) in the
indicated location.
45
30
32
30
37
